VFC MP7 Steel Bolt Carrier – Short CQB Verson (190g) - V2

VFC MP7 Steel Bolt Carrier – Short CQB Verson (190g) - V2

CP0027

€136,85 EUR
€136,85 EUR
Sale Ausverkauft
Inkl. Steuern. Versand wird beim Checkout berechnet

Auf Lager
⚠️ DIY Installation Required: This V2 bolt carrier requires installation of the included nozzle return spring system. A new nozzle return spring, M2 steel pin, and M2 drill are included. Technical confidence and careful assembly are required.

CNC Steel Bolt Carrier V2 for VFC MP7 GBB – Short Lightweight Version

The Short Lightweight V2 Steel Bolt Carrier is engineered for practical skirmishers who want improved reliability, higher rate of fire, and better gas efficiency from the VFC MP7 GBB platform.

Precision CNC-machined from hardened #45 steel and finished with a QPQ nitrided surface treatment, this bolt carrier offers the strength and wear resistance expected from a serious steel upgrade, while keeping the moving mass lower than a full-weight carrier.

V2 Highlight – New Nozzle Return Spring System

The V2 version introduces a completely redesigned nozzle return spring layout, similar in concept to the system used in VFC G36 and AR15 GBB platforms.

Instead of relying on the original exposed factory-style spring arrangement, the nozzle return spring with guide rings now sits inside the nozzle. This design directly addresses the known issue of crushed nozzle return springs caused by the factory layout.

Key Features

  • Short lightweight configuration for practical skirmishing
  • Precision CNC-machined from hardened #45 steel
  • QPQ nitrided surface treatment for wear resistance and long-term durability
  • New V2 internal nozzle return spring system
  • Helps eliminate the crushed nozzle return spring issue caused by the original factory design
  • Excellent gas efficiency, especially useful in cooler conditions
  • Higher rate of fire compared to standard-weight steel bolt carriers
  • Improves long-term reliability and helps avoid bolt stop malfunctions after extended use
  • Compatible with all VFC MP7 GBB models

Why Choose the Short Lightweight Version?

Compared with a heavier full-length steel carrier, the short lightweight version keeps the system more responsive and gas-efficient. This makes it especially attractive for players who actually use their MP7 on the field rather than only building for maximum recoil feel.

The reduced moving mass helps maintain a snappier cycle, supports a higher rate of fire, and performs better in colder weather or longer skirmish sessions where gas efficiency matters.

Technical Specifications

Compatibility All VFC MP7 GBB models
Version V2 Short Lightweight Version
Weight Approx. 190g
Material Hardened #45 steel
Surface Treatment QPQ nitrided finish
Gas Requirement Approx. 130 PSI and above recommended
Recommended Backplate Optional
Use Case Practical skirmishing, winter use, higher ROF, improved gas efficiency

Included Parts

  • 1x CNC steel short lightweight bolt carrier
  • 1x new nozzle return spring with CNC aluminum spring plug
  • 1x steel pin
  • 1x M2 drill
  • 1x CNC aluminum nozzle stop and its screws: 2x M3X10

Nozzle and other internal MP7 components are not included unless explicitly shown or stated.

Installation Tutorial V2

Type 1 (also the easy one)

  1. Don't assemble the silver V2 nozzle return spring plug, just put the included small o-ring on it (the side with threads), then use a big flat screwdriver to push it to the rear hole of the bolt carrier, use the M3x6 hex socket countersunk screw to fix it to the rear of bolt carrier. This would seal the bolt carrier to let you further use it as factory default configuration.
  2. Put the nozzle with the OEM or included nozzle return spring back to the bolt carrier and install the included nozzle stop. Done

Type 2 (the future-proof one, but request some DIY ability and a drill to modify the nozzle)

  1. Assemble the nozzle return spring plug like this
  2. Use the included M2 drill to drill a hole on each side of the nozzle, the position is 25.0mm from rear. Use a pencil to correctly mark the position before drilling, because you only have 1 try. Do it side after side, don't drill through, otherwise the drill will come out from a wrong hole and your nozzle will be trashed.
  3. Put the nozzle assembly back to bolt carrier, install the M3x6 hex socket countersunk screw
  4. Don't install the long OEM nozzle return spring anymore. Just put back the nozzle stop, then you are good to go

Compatibility Notes

  • Compatible with all VFC MP7 GBB models
  • Designed for users prioritizing reliability, gas efficiency, and practical field performance
  • Recommended gas pressure: approx. 130 PSI and above
  • Optional reinforced backplate upgrade may be used for a more robust overall setup

Package Disclaimer

This product is intended for airsoft use only. Installation requires technical care and basic modification work. Improper installation, drilling, or assembly may affect function and is not considered a product defect.
